MSP430F2232IDAR

mixed signal microcontroller, 2 mA, 4.1 V, 38-TSSOP.

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.10~8.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.10~8.30

PartNumber:: MSP430F2232IDAR

Brand:: Texas Instruments - TI | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. John's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-19

From Other Seller

Part Number:MSP430F2232IDAR
US $3.10 - 8.30
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MSP430F2232IDAR is a mixed signal microcontroller. The Texas Instruments MSP430 family of ultralow－power microcontrollers consist of several devices featuring different sets of peripherals targeted for various applications. The MSP430F2232IDAR, combined with five low－power modes is optimized to achieve extended battery life in portablemeasurement applications. The MSP430F2232IDAR features a powerful 16－bit RISC CPU, 16－bit registers, and constant generators that contribute to maximum code efficiency.The digitally controlled oscillator (DCO) allows wake－up from low－power modes to active mode in less than 1 μs.

Parametrics

MSP430F2232IDAR absolute maximum ratings: (1)Voltage applied at VCC to VSS: －0.3 V to 4.1 V; (2)Voltage applied to any pin (see Note): －0.3 V to VCC + 0.3 V; (3)Diode current at any device terminal: ±2 mA; (4)Storage temperature, Tstg: Unprogrammed device: －55°C to 150°C, Programmed device:－55°C to 105°C.

Features

MSP430F2232IDAR features: (1)Low Supply Voltage Range: 1.8 V to 3.6 V; (2)Ultralow Power Consumption: Active Mode: 270 μA at 1 MHz, 2.2 V, Standby Mode: 0.7 μA, Off Mode (RAM Retention): 0.1 μA; (3)Ultrafast Wake－Up From Standby Mode in Less Than 1 μs; (4)16－Bit RISC Architecture, 62.5－ns Instruction Cycle Time; (5)Two Configurable Operational Amplifiers (MSP430x22x4 Only); (6)Brownout Detector; (7)Serial Onboard Programming, No External Programming Voltage Needed Programmable Code Protection by Security Fuse; (8)Bootstrap Loader; (9)On Chip Emulation Module.
