Product Summary
The REF3025AIDBZR is a cmos voltage reference available in a tiny SOT23－3. The REF3025AIDBZR small size and low power consumption (50μA max) make it ideal for portable and battery－powered applications. The REF3025AIDBZR does not require a load capacitor. Unloaded, the REF3025AIDBZR can be operated with supplies within 1mV of output voltage. All models are specified for the wide temperature range, －40°C to +125°C.
Parametrics
REF3025AIDBZR absolute maximum ratings: (1)Supply Voltage, V+ to V－: 7.0V; (2)Output Short－Circuit(2): Continuous; (3)Operating Temperature: –40°C to +125°C; (4)Storage Temperature: –65°C to +150°C; (5)Junction Temperature: +150°C; (6)Lead Temperature (soldering, 10s): +300°C.
Features
REF3025AIDBZR features: (1) microsize package: sot23-3; (2) low dropout: 1mv; (3) high output current: 25ma; (4) high accuracy: 0.2%; (5) low iq: 50μa max; (6) excellent specified drift performance: 50ppm/℃ (max) from 0℃ to +70℃, 75ppm/℃ (max) from –40℃ to +125℃.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 REF3025AIDBZR |
Texas Instruments |
Voltage & Current References 2.5V 50ppm/DegC 50uA SOT23-3 Series |
Data Sheet |
|
|
||||||||||||
|
REF3025AIDBZRG4 |
Texas Instruments |
Voltage & Current References 2.5V 50ppm/Degrees C 50uA Vltg Ref |
Data Sheet |
|
|
||||||||||||
