Product Summary

The MSP430F448IPZR is a mixed signal microcontroller. The Texas Instruments MSP430 family of ultralow power microcontrollers consists of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low－power modes, is optimized to achieve extended battery life in portable measurement applications. The MSP430F448IPZR features a powerful 16－bit RISC CPU, 16－bit registers, and constant generators that contribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows wake－up from low－power modes to active mode in less than 6 μs.

Parametrics

MSP430F448IPZR absolute maximum ratings: (1)Voltage applied at VCC to VSS: －0.3 V to 4.1 V; (2)Voltage applied to any pin (see Note): －0.3 V to VCC + 0.3 V; (3)Diode current at any device terminal: ±2 mA; (4)Storage temperature, Tstg: Unprogrammed device: －55°C to 150°C, Programmed device:－55°C to 85°C.

Features

MSP430F448IPZR features: (1)Five Power Saving Modes; (2)Wake－Up From Standby Mode in Less Than 6 μs; (3)16－Bit RISC Architecture, 125－ns Instruction Cycle Time; (4)12－Bit A/D Converter With Internal Reference, Sample－and－Hold and Autoscan Feature; (5)16－Bit Timer B With Three or Seven Capture/Compare－With－Shadow Registers; (6)16－Bit Timer A With Three Capture/Compare Registers; (7)On－Chip Comparator.

Diagrams

MSP430F448IPZR pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MSP430F448IPZR
MSP430F448IPZR
Texas Instruments
16-bit Microcontrollers (MCU) 48kB Flash 2MB RAM 12ADC/2USART 160sLCD
Data Sheet
0-790: $2.99
790-1000: $2.93
