MAX3232ESE+T

transceiver, -0.3V to +6V, SOP-16, 1μA Low-Power Shutdown, Low Supply Current

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.80~6.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.80~6.30

PartNumber:: MAX3232ESE+T

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. John's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-31

From Other Seller

Part Number:MAX3232ESE+T
US $2.80 - 6.30
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX3232ESE+T transceiver has a proprietary low-dropout transmitter output stage enabling true RS-232 performance from a 3.0V to 5.5V supply with a dual charge pump. It requires only four small 0.1μF external chargepump capacitors. The MAX3232ESE+T is guaranteed to run at data rates of 120kbps while maintaining RS-232 output levels. The applications of MAX3232ESE+T the include Notebook, Subnotebook, and Palmtop Computers, High-Speed Modems, Battery-Powered Equipment, Hand-Held Equipment, Peripherals, Printers.

Parametrics

MAX3232ESE+T absolute maximum ratings: (1)VCC: -0.3V to +6V; (2)V+: -0.3V to +7V; (3)V-: +0.3V to -7V; (4)V+ + V-: +13V; (5)Input Voltages: T_IN, SHDN, EN: -0.3V to +6V, MBAUD: -0.3V to (VCC + 0.3V), R_IN: ±25V; (6)Output Voltages: T_OUT: ±13.2V, R_OUT: -0.3V to (VCC + 0.3V); (7)Short-Circuit Duration: T_OUT: Continuous; (8)Operating Temperature Ranges: 0 to +70℃; (9)Storage Temperature Range: -65℃ to +150℃; (10)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX3232ESE+T features: (1)Low Supply Current: 300μA; (2)Guaranteed Data Rate: 120kbps; (3)1μA Low-Power Shutdown with Receivers Active; (4)Meets EIA/TIA-232 Specifications Down to 3.0V; (5)Pin Compatible with Industry-Standard MAX232; (6)Guaranteed Slew Rate: 6V/μs.
